Temperature effect on full scale output: 0,02% / 10°C
Compensated Temperature Range: -10°C/+50°C
Operating Temperature Range: -20°C/+60°C
Creep error after 30 minutes: 0,02% F.S.
Recommended excitation voltage: 10 Vdc
Maximum tolerated excitation voltage: 15 Vdc
Input Resistance: 750 ± 10 Ohm
Output Resistance: 700 ± 5 Ohm
Zero Balance: +/-1% F.S.
Insulation Resistance: >5000 MOhm
Safe Overload: 120% F.S.
4-wire shielded cable, 5 mm diameter: - 5 m long for CPX 250...5000 versions; - 10 m long for CPX 7500...100000 versions.
The CCATEX certificate makes the load cell suitable for use in hazardous areas with protection methods according to: ATEX II 1G Ex ia IIC T6 (Ta -20÷+40°C) TX (Ta -20÷+65°C) Ga ATEX II 1D Ex ta IIIC TX°C (Ta -20÷+40°C) TX°C (Ta -20÷+65°C) Da IP65. The certificate includes the manual and the ATEX CE conformity declaration (available in EN, DE, FR, and IT).
The CCATEX certificate is issued after the checks done by qualified technicians, with the help of specific equipments, for each load cell.
IMPORTANT: the certificate refers to the single load cell. For systems with more load cells, it is necessary to order one certificate for each load cell.
