Weight indicator in cabin with 17-key numerical/functional waterproof keypad, LCD backlit display with 6 high contrast 25-mm digits and easy to clean Waterproof IP65 ABS case resistant to harsh and corrosive environments. Integrated radio module, for communication with the weighing forks.
Second weight indicator, attached to the forks, with 5-key numerical/functional waterproof keypad, LCD backlit display with 6 high contrast 25-mm digits protected in thick steel case. Integrated radio module, for communication with the indicator in cabin.
Structure of the forks in painted steel with IP65 protection degree.
Each fork weighs 75 kg (LTF25) and 90 kg (LTF50).
Functions with 4 shear-beam IP68 load cells
Accuracy: +/- 0.2% of the capacity
Max. allowable overload: 200% of the nominal capacity.
Max. horizontal inclination (flexibility): +/- 2° with the same precision features.
Digital calibration and set-up through keyboard or PC with DINITOOLS.
Forks power supply through rechargeable battery, 40-hour approximate operating time
Indicator in cabin power supply through rechargeable battery (40-hour approximate operating time) or directly from the lift truck through optional power adapter.
Programmable auto power saving function.
Equipped with battery charger.
KEYBOARD FUNCTIONS AND PRINTOUT
KEYBOARD: clearing, semi automatic tare, presettable tare, print and/or data transmission, selectable function command, on/off.
